SCHNEIDER TSXAEY800 Premium Analog Input 8
Essential Information
SCHNEIDER TSXAEY800 Premium Analog Input 8
- Number:
- TSXAEY800
- Product Orgin:
- France
- Warranty:
- 1 year
- Inventory Quantity:
- 3
- Shipping Port:
- Xiamen
- Payment:
Description
SCHNEIDER TSXAEY800 Premium Analog Input 8
⚙Product Overview
The SCHNEIDER TSXAEY800 is a DIO drop interface module for the Modicon Quantum automation platform. It forms the head end of a distributed I/O (DIO) drop station, connecting a local Quantum I/O rack to the PLC processor over a Modbus Plus (MB+) network. The module provides the 5 V DC backplane supply for the I/O modules in the drop, accepts AC line power directly, and supports single-port redundant MB+ operation. It is widely used in water/wastewater, process, and infrastructure plants with installed Quantum distributed I/O architectures.
🔨Product Specifications
- 🔶Manufacturer: Schneider Electric
- 🔶Model / Part Number: TSXAEY800
- 🔶Product Range: Modicon Quantum Automation Platform
- 🔶Product Type: DIO Drop Interface (distributed I/O station head module)
- 🔶Network: Modbus Plus (MB+) — 1 port (redundant-capable)
- 🔶Power Supply: 115 / 230 V AC
- 🔶Supply Frequency: 47–63 Hz
- 🔶Rated Power: 50 VA
- 🔶Max Supply Current: 0.2 A @ 115 V; 0.4 A @ 230 V
- 🔶Inrush Current: 10 A @ 115 V; 20 A @ 230 V
- 🔶Backplane Output: 5.1 V DC, 3 A (for I/O modules in the drop)
- 🔶Fuse: 1.5 A
🔨Key Features
- 🔶Direct AC Line Power: Accepts 115/230 V AC at the drop, eliminating a separate 24 V DC power converter at remote stations.
- 🔶Integrated Backplane Supply: Outputs 5.1 V DC / 3 A to power the I/O modules installed in the drop rack.
- 🔶Modbus Plus Connectivity: Connects the distributed I/O station to the Quantum PLC over the proven MB+ network; single-port version with redundancy capability.
🔨Typical Applications
- 🔶Distributed I/O stations in Quantum PLC systems
- 🔶Water and wastewater plant instrumentation I/O
- 🔶Process skid and packaged-unit remote I/O
- 🔶Replacement and spare-part supply for installed Quantum DIO drops
✔Ordering Notes
- 🔶Verify the power version: The TSXAEY800 is the AC-powered DIO drop (115/230 V AC).
- 🔶Check the MB+ network segment: Confirm the drop address and Modbus Plus cable/segment arrangement match your existing network before commissioning.
